Phenolic pressure gauge

Phenolic Case, sS316 internal, glycerin filled

Accuracy class 1.0%

Nominal size: 115mm

Version:

PG.BR.PHENOLIC(UK)

PG.NV.PHENOLIC (Italy)

Description:

Phenolic Pressure Gauges are specifically design for demanding applications in the chemical and petroleum processing industries, as well as many other industrial applications. The cases are constructed of a rugged, corrosion-resistant phenolic material. The solid front, safety case design with a blow-out back insulates the gauge face from the pressure measuring system and assures operator protection with safety glass lenses. Bourdon tubes and connections are made of all 316 stainless steel. This type of gauge provides high accuracy compared to other types of gauges.

Features:

• Dial Diameters: 115mm
• Available Ranges: -1-0 bar, 0-0.68 bar/psi through to 2000 bar/psi
• Accuracy Class:  ± 0.5% or ± 1.0%
• Case: Phenolic Case
• Medium: Glycerin (Fillable but Dry)
• Connection Type: Stainless Steal
• Connection Size: G 1/2 or 1/2 NPT
• Operating Temperature: -20 to +180°C

Applications:

• Iron & steel industry
• Power stations
• General mechanical eng.
• Pumps
• Hydraulics
• Compressors
• Water treatment plants



Datasheet

Brannan Brand (UK)

115mm

Nuova Fima Brand (Italy)

115mm
